E-Liquid Chubby Gorilla Bottle Filling Machine
Automatic filling, plugging, capping and optional labeling solution for 10ml, 30ml, 60ml, 100ml and 120ml Chubby Gorilla bottles.
This machine is built for e-liquid, e-juice, vape juice, nicotine salt liquid, CBD oil, tincture, essential oil and other small bottle liquid products. It supports peristaltic, piston or ceramic pump filling systems based on liquid viscosity and accuracy requirements.
With anti-drip filling nozzles, PLC touch screen control and quick-change bottle parts, the line helps e-liquid manufacturers improve filling accuracy, reduce leakage and handle different bottle sizes with less downtime.
Suitable Bottles: Chubby Gorilla bottle, unicorn bottle, vape juice bottle, dropper bottle, small PET bottle
Optional Functions: Bottle feeding, filling, plug inserting, capping, labeling cartoning and coding
Application: E-liquid factory, vape juice brand, OEM filling line and small bottle liquid packaging
10ml E-liquid Filling Machine Line
What you can get from us?
Parameter:
- Model: Automatic e-liquid filling machine
- Filling volume: 5-120ml(customized)
- Filling nozzles: 1-8 nozzles for your optional(customized)
- Filling speed: 10-100BPM for your optional(customized)
- Filling method:With peristaltic pump and piston pump filling solution for your optional
- Filling accuracy: ±0.5%(according to product)
- Capping rate: ≥99.99%
- Power supply: Single phase 110V/220V,50/60Hz or three phase 380V/440V 50/60Hz(customized)
- Total dimension: 2100mm*1350mm*2050mm(customized)
Highlight:
1.Adopt peristaltic pumps for filling, which are mainly suitable for low-viscosity materials and filling multiple flavors. They can quickly switch and clean electronic cigarette materials for different flavors within 5 minutes.
2.Adopt piston pumps for filling, suitable for materials of different viscosities (especially for high viscosity, currently popular filling method). With servo motor control, it can automatically adjust the filling quantity, making it convenient for customer operation and use
1.It can quickly change for different diameter bottles within 30 minutes
2.It can change for both glass dropper bottles and plastic dropper bottles at the same machine with 60 minutes
The machine use servo control to automatically adjust the filling volume, making it convenient for customer operation
The machine is equipped with an organic glass cover featuring a door stop function to ensure operational safety. Additionally, it comes with a 360-degree rotatable touchscreen for customer-friendly operation and use
What we can offer you:
FAQ:
Our servo-driven filling systems achieve a filling accuracy of ±1%. this precision ensures you meet strict regulatory labeling requirements while saving money by eliminating product giveaway.
Yes, our modular designs allow the filler to integrate seamlessly with your existing downstream packaging equipment, communicating via standardized PLC protocols.
Yes. The system uses high-precision photoelectric sensors. If a bottle is missing, tipped over, or jammed, the machine pauses the filling process automatically to prevent product waste and messy spills.
This machine is suitable for e-liquid, vape juice, e-juice, nicotine liquid, CBD oil, essential oil, tincture, oral liquid, serum and other low-to-medium viscosity liquids. If your liquid contains high VG, thicker oil or special ingredients, we can test your sample before confirming the best filling system.
Yes. The e liquid filling machine can be adjusted for different PG/VG ratios. For thicker high-VG formulas, we may recommend a servo piston pump or other suitable filling method to keep stable filling accuracy and reduce dripping.
