Automatic petroleum jelly filling machine

Hot filling and cooling solution for Vaseline, petroleum jelly, balm, ointment, wax and high-viscosity cosmetic products

This automatic petroleum jelly filling machine is designed for thick, heat-sensitive and high-viscosity products such as petroleum jelly, Vaseline, balm, ointment, cosmetic cream, wax, gel and similar paste products. With a heated hopper, mixing system and piston filling structure, the machine keeps the material flowing smoothly during filling and helps reduce dripping, blocking and uneven filling volume.

Key Features:
  • Heated filling system for petroleum jelly, Vaseline, balm, wax and thick paste products
  • Servo piston filling for stable volume control and clean filling performance
  • Suitable for jars, tins and bottles with different shapes and filling volumes
  • Optional mixing and temperature control to keep viscous material in good flow condition
  • Complete line available with capping, foil sealing, cooling, labeling and conveyor system
  • Custom design support based on your sample container, filling volume and production speed

Send us your container size, filling volume and target capacity. We will help you design a suitable petroleum jelly filling machine or complete automatic Vaseline filling line.

Facebook
LinkedIn
Pinterest
WhatsApp
automatic-petroleum-jelly-filling-machine-line
petroleum-jelly-filling-machine-advantages
high-viscosity-product-filling-applications-container-guide

Automatic Petroleum Jelly Filling Machine Line

Working video:

What we can offer you:

  • 100% Refund Policy

    If the quality is poor or it can’t run your product, we guarantee a 100% full refund for your peace of mind

  • Two years warranty

    Any equipment purchased from us comes with a two-year warranty.we provide free replacements and cover shipping for parts under 10kg damaged due to quality issues, not deliberate damage

  • Attentive after-sales service

    We promise: all equipment purchased from us is backed by comprehensive after-sales service and lifetime benefits.

  • Timely production and delivery

    We oversee the entire process from receiving samples to design and production, providing timely photos and videos to showcase the entire process to ensure the efficiency of equipment production and timely delivery

Parameter:

  • Model: Automatic petroleum jelly filling machine
  • Filling volume: 50-2000ml(customized)
  • Filling nozzles: 1-12 nozzles for your optional(customized)
  • Filling speed: 10-100BPM for your  optional(customized)
  • Filling method: Piston pump for filling with servo motor control
  • Filling accuracy: ±1%(according to product)
  • Capping rate: ≥99.99%
  • Power supply: Single phase 110V/220V,50/60Hz or three phase 380V/440V 50/60Hz(customized)
  • Total dimension: 1930mm*1520mm*2010mm(customized)

Highlight:



1.It use piston pumps for filling, suitable for materials of different viscosities (especially for high viscosity).

2.With servo motor control, it can automatically adjust the filling volume, making it convenient for customer operation and use

1.It can quickly change for different diameter jars

1.The hopper with mixer and it is double jacket with heating function and make it more easier to do filling for high viscosity products

2.Machine also comes with cleaning function that can do cleaning automatically after finish filling

The machine is equipped with an organic glass cover featuring a door stop function to ensure operational safety. Additionally, it comes with a 360-degree rotatable touchscreen for customer-friendly operation and use

What you can get with our petroleum jelly filling machine line:

contact_us_honest_machinery

Related Products:

FAQ:

For most petroleum jelly products, a hot filling system is strongly recommended. Petroleum jelly is a high-viscosity material and usually becomes easier to pump and fill when kept at a controlled temperature. A heated hopper with mixing helps maintain smooth flow, reduces nozzle blocking, and improves fill consistency. If the formula becomes too thick at room temperature, hot filling is the safer and more stable option. Your machine can be customized with heating and mixing functions according to your product formula and filling temperature requirements. Your product page specifically states that the machine is designed for thick, heat-sensitive and high-viscosity products and uses a heated hopper plus mixing system to keep material flowing smoothly. Similar official product pages also describe petroleum jelly systems as hot filling + cooling lines

This is a very important point for petroleum jelly packaging. Fill accuracy depends not only on the filling method, but also on temperature control, product consistency, and the filling/cooling process. A servo-controlled piston filling system helps keep the fill volume stable, while proper heating and mixing reduce viscosity fluctuations during production. If your product has noticeable shrinkage after cooling, we can also consider process adjustments such as setting the correct filling temperature, optimizing fill volume, and adding cooling or surface finishing steps to improve the final appearance and net content consistency.

Yes, in many cases it can. The petroleum jelly filling machine can be designed for different container types such as plastic jars, glass jars and metal tins, as long as the container dimensions, opening size and filling volume range are confirmed in advance. If the size difference between containers is large, some change parts may be needed for a faster and more stable changeover. On your product page, the machine is described as suitable for jars, tins and bottles with different shapes and volumes, and it also mentions quick changeover for different jar diameters. Similar official product pages also show petroleum jelly equipment being used for square jars, round jars, flat jars and metal/aluminum tins

A smooth product surface is a common quality requirement for petroleum jelly, balm and wax products. To achieve this, the line may include controlled hot filling, cooling, and in some cases a reheating or surface finishing step. The right process depends on your formula, filling temperature, jar size and required final appearance. If surface flatness is important for your retail packaging, we can evaluate whether you need only a heated filling machine or a more complete line with cooling and additional finishing sections to improve the final presentation. Competing official petroleum jelly lines commonly include cooling and even reheating steps specifically to improve solidification and top-surface finish

Yes, it can be designed for easier cleaning and product changeover. For petroleum jelly and similar thick products, cleaning convenience is very important, especially if you run different fragrances, medicated formulas or cosmetic variants. Your product page mentions that the hopper can be equipped with a cleaning function, which helps after finishing production. In practical use, the cleaning method will depend on the product characteristics and your factory’s cleaning process. If you plan to run multiple SKUs, we can optimize the hopper structure, pipeline layout and contact parts to make cleaning faster and reduce residue left inside the filling system
